VIBRATING SCREENS

Vibrating screens are used for sifting or fractioning bulk raw materials. Powered by realiable inertial drives, individually selected for every device.

We can distinguish one-deck and multi-deck screens, covered or open. Our offer contains full variety.

Linear vibrating screens

Przesiewacze wibracyjne

One-deck – produces two fractions. Also used to eliminate too big chunks before packaging or quality/control device.

Multi-deck – produces any number of desired fractions.

Table below shows basic technical data.

Basic technical data
Maximum dimensions (length x width)5m x 2m
Construction materialStainless steel AISI 304
Stainless steel AISI 316
Coated carbon steel
DriveInertial drive
SupportBar support construction with springs or steel/rubber hangers
ScreenPerforated steel sheet or mesh
1
2
3
4
5
1

Vibrating screen

2

Interia drive

Wibrator elektryczny do zastosowań w przemyśle

3

Hopper tank

4

Outlet of the superfraction

5

Outlet of the subfraction

Rotating vibrating screen

Przesiewacze wibracyjne, selektory

MR-type rotating vibrating screen – selects solids from liquids or divides bulk material fractions (grain size from 0,033 mm to 51 mm). One device may contain from 1 to 4 screens. Standard models are equipped with screens from 440 mm to 1800 mm diameter. Easy to assemble and disassemble. Self-cleaning system are available. All product contact areas can be polished to be in accordance with Sanitary Standards.

VAN-type rotating vibrating screen – VAN-type rotating screen – is used mainly for fractioning or dust removal from dry, powdered or granulated products. Screens are moving in three directions similar to hand sifting. Perfect for light, delicate and crunchy substances. Maximum number of screens – 5. Standard models are equipped with screens from 1200 mm to 2600 mm diameter.

MSC-type rotating vibrating screen – is used mainly for control sifting. Removes unwanted bigger objects from product. The device is designated for granulates, powders and liquids. Grain size from 0,5 mm to 51 mm. Powered by two inertial drives installed horizontally which makes the device compact. Standard models are equipped with screens from 440 mm to 2200 mm diameter.

On request: ATEX certification, FDA IQ-OQ procedure, GMP can be provided. atex

Basic technical data
Rotating screen MR Rotating screen VANRotating screen MSC
Particle sizes rangingfrom 0,033 mm to 51 mmfrom 0,033 mm to 51 mmfrom 0,5 mm to 51 mm
Number of screensup to 4up to 51
Screen diameterfrom Ø440 mm to Ø1800 mmfrom Ø1200 mm to Ø2600 mmfrom Ø440 mm to Ø2200 mm
Construction materialStainless steel AISI 304
Stainless steel AISI 316
Carbon steel
Stainless steel AISI 304
Stainless steel AISI 316
Carbon steel
Stainless steel AISI 304
Stainless steel AISI 316
Carbon steel
